◆High luminous efficacy 145lm/W in the industry,energy saving more than 81% compared with traditional mercury lamp!
--------------------------------------------------------------------------------------------
◆Safety and reassuring lightweight design with 560g
--------------------------------------------------------------------------------------------
◆With 360°wide angle it can be used in many places
--------------------------------------------------------------------------------------------
Catalogue
Instruction for use
Power is greatly controlled by using high brightness LED chip and optical design. Energy saving is more than 81% since the 160W mercury lamp was turned into 30W LED corn light.
Safety and reassuring lightweight design with 560g
After realizing 560g lightweight design with our special heat dissipation techniques, the burden of lighting is perfectly suppressed, it is also bright with good energy saving effect, so it is very safe to use.
With 360°wide angle it can be used in many places
With 360°wide angle of irradiation, so it can be used as garden light, warehouse light,street light and so on.
Heat dissipation and lifespan improved with low current driving design
The product is not only designed with cost saving consideration,but also with durability,driven by a current which is under the specified current,the problem of heat dissipation is successfully improved, so it is a long life lamp.
Reassuring warranty of 3 years
The warranty of product is 3 years.
It can be used without replacing appliance
It can be used in traditional E27/E40 Base, so it is unnecessary to replace the appliance.
Reducing environmental load
There is no doubt that our products do not contain harmful substances such as mercury. and it's always eco-friendly from the reduction of carbon dioxide caused by energy saving to the process of production and so on.
Parameters
Item |
AM-F30W-N |
Beam angle |
360° |
Luminous flux |
4350lm±5% |
Luminous flux efficiency |
145lm/W±5% |
Color temperature |
5000K±500K(3000K 6000K is available too) |
color rendering index(CRI) |
Ra85±5 |
LED chip |
SMD(produced by LG) |
Power |
30W±5%(including power supply) |
Input voltage |
AC100-240V |
Wave index |
50Hz/60Hz |
Power |
Built-in power supply |
Size |
82*256mm(E27 Base) / 82*263mm(E40 Base) |
Weight |
About 560g |
Body |
Aluminum |
Lampshade |
Polycarbonate |
Lamp holder |
E27/E40 |
Working temperature |
-20 - +40℃ |
Preservation temperature |
-20 - +40℃ |
Lifespan |
40000H |
Warranty |
3 years |
※Lifespan is the time before the initial luminous flux decays to 70%,and it is a average value,not guaranteed value.
※Please be noted because there is a deviation of the LED, so the light color and brightness may vary for each element.
※In order to improve the product,sometimes there will have a change in specification and appearance without notice,please note.
